Custom Industrial Chemical Liquid Mixer Equipment Manufacturers

Jiangsu Syeelai Environmental Technology Co., Ltd. (SYEELAI) is a manufacturing enterprise integrating R&D, production, sales and service. As Custom Industrial Chemical Liquid Mixer Equipment Manufacturers in China, we build liquid agitators for chemical processing, environmental protection, water treatment, electroplating, new energy and pharmaceutical plants.

Our liquid mixer range reaches from portable batch units to heavy-duty gear-driven agitators, covering high-speed dispersion, homogenization, solid-liquid blending and gentle reaction mixing. Because we also manufacture metering pumps, chemical pumps, filters and valve accessories, we can supply one mixer or a complete mixing, dosing and transfer loop. the category sets out the range, how we configure it and the project information we use to prepare an accurate proposal.

Liquid Mixer Range and Positioning

We organise the range by drive and transmission type because that determines torque, speed range, footprint and service access. The following configurations are available:

• Type C Mobile Mixer – portable top-entry mixer for on-site batch preparation, temporary mixing and small-volume treatment duties.
• Type BLD Cycloidal Pinwheel Transmission Mixer – compact cycloidal gear drive based on the planetary transmission principle, suited to continuous and batch mixing in water and chemical service.
• Type RF Coaxial Gear Transmission Mixer – in-line coaxial gear drive for high-efficiency homogenisation and broader viscosity applications.
• Type KF Right-angle Shaft Gear Drive Mixer – right-angle shaft output for installations with vertical space constraints or non-standard tank access.
• Type FF Parallel Shaft Gear Drive Mixer – parallel shaft helical gear transmission for robust torque delivery and stable medium-speed mixing.
• Type CV Gear Drive Mixer – premium transmission unit for variable-load process duties where duty cycles change during operation.

For the complete product family, see our Mixer category.

Transmission Selection at a Glance

Materials, Chemical Compatibility and Application Fit

Wetted components are selected after reviewing chemical composition, temperature, solids content and viscosity. Our mixer line uses corrosion-resistant construction options including PP, FRP and stainless steel, with elastomer and seal choices matched to the media.

• Chemical and petrochemical: reagent dilution, reactor charging, neutralisation and solid-liquid blending.
• Electroplating and surface treatment: acid and alkali bath circulation, brightener mixing, rinse tank agitation.
• Water and wastewater: coagulant dissolution, pH adjustment, flocculation and sludge conditioning.
• New energy: slurry preparation, precursor mixing and auxiliary chemical dosing.
• Pharmaceutical: controlled blending where low shear, cleanability and batch repeatability matter.

We do not select a mixer by tank volume alone. Viscosity, required flow pattern, solid suspension level, heat or mass transfer and available motor power all affect geometry and drive rating.

Configuring the Mixer for Your Tank and Process

A mixer proposal from our engineering team covers impeller type, shaft length and diameter, speed, baffling, mounting interface, seal arrangement, motor rating and access requirements. We work from the tank drawing and process working point rather than a one-size-fits-all table.

• Mounting: top entry, side entry, portable frame, flange or foot-mounted drive.
• Speed control: fixed-speed motor, variable frequency drive, or gear transmission matched to viscosity changes.
• Impeller selection: axial-flow for turnover and suspension, radial-flow for dispersion, or high-shear for rapid dissolution.
• Sealing: mechanical seal, packing or sealless design based on corrosive exposure and vapour containment needs.
• Tank geometry: baffles, nozzles, tank material and platform constraints are included in the arrangement drawing.

Controls, Automation and Dosing Integration

We supply mixers as standalone machines or integrate them into automated dosing skids. Control interfaces can include local start/stop, VFD speed setpoints, remote HMI or PLC signals and interlocking with metering pumps, level sensors, pH or ORP controllers and transfer pumps.

For process packages, the mixer is coordinated with our Chemical Pump range and our chemical mixing and dosing solution engineering package. This avoids mismatched speeds, pipe sizes and control logic between separate suppliers.

Installation, Acceptance and Maintenance

Our scope includes non-standard equipment installation and commissioning. We provide on-site guidance for mechanical installation, electrical connection and trial operation, supported by remote diagnosis and 24/7 responsive service.

Before shipment from our factory, each mixer passes full-performance verification. We keep acceptance records, prepare equipment documentation and use industrial-grade protective packaging for sea and land transport. After commissioning, we establish a service file and track operating status where our service agreement applies.

Quality Assurance and Traceability

We operate a full-chain quality inspection system: raw material sampling and verification on arrival, fixed-point patrol inspection during machining and assembly, and full-performance testing of finished mixers. Inspection data is retained throughout the process for traceability.

For project-specific compliance, we confirm applicable standards and documentation at quotation stage and can prepare inspection records, material certificates and dimensional reports according to the delivery specification.

Information We Use to Configure Your Solution

Send the following data with your enquiry, or share what is available and our engineers will identify the missing points. The proposal is based on the actual working point, not on tank volume alone.

Liquid Mixer Project FAQs
