  • YM25/32 Series Peristaltic Hose Pump
  • YM25/32 Series Peristaltic Hose Pump

Key Features

1. The medium flow range from 180 L/h to 3000 L/h fully covers the Hose Pump models YM25 and YM32. The competitiveness of these models stems from both economic and technical perspectives, giving the product range an unrivalled advantage in the market. Featuring a highly efficient and heavy-duty design, they deliver maximum metering accuracy, efficiency, and durability together with the hose.

2. With no check valves or sealed water flushing systems required, the pumps offer dry-run capability and strong suction, making them the optimal peristaltic (hose) pumps for dosing applications, or for transferring highly abrasive, shear-sensitive, viscous, or corrosive media.

3. The robustness of the YM25 and YM32 hose pumps is based on two integrated bearings that absorb loads between the rotor and the gearbox. The rotor assembly and rollers feature maximum performance and an innovative design, together with a compact, easy-to-install pump system and an extremely sturdy pump casing. They can fully handle the latest hardening and anti-corrosion treatments equivalent to those available on the market.

4. The output shaft of the bearing housing is connected to the rotor via a locking assembly. The greatest advantage of this design is easy installation and disassembly, effectively reducing maintenance difficulty and time required.




Model Rated Flow Rate Maximum Flow Rate Flow Rate Per Revolution Maximum Pressure Maximum Temperature Resistance of Hose Hose Inner Diameter Rated Speed Rated Power Connection Type Weight
YM-25 774 L/h 1440 L/h 0.3 L/rev 10 Bar 95℃ φ25 mm 43 rpm 1.1 kW DN25 Flange 70 kg
YM-32 1613 L/h 3000 L/h 0.625 L/rev 10 Bar 95℃ φ32 mm 43 rpm 1.5 kW DN32 Flange 100 kg
